| MODEL/ITEM |
RM-3400A |
RM-2400A |
RM-6500A |
RM-5500A |
| 8Ωstereo power (RMS/THD1%) |
500W |
350W |
250W |
200W |
| 4Ωstereo power (RMS/THD1%) |
700W×2 |
500W×2 |
350W×2 |
250W×2 |
| 2Ωstereo power (EIA/THD1%) |
1000W×2 |
N/A |
N/A |
N/A |
| 8Ωbridge power (RMS/THD1%) |
1400W |
900W |
600W |
N/A |
| 4Ωbridge power (EIA/THD1%) |
N/A |
N/A |
2000W |
2500W |
| Frequency response |
20Hz~20KHz |
| THD+N (THD%) |
＜0.05% |
＜0.05% |
＜0.05% |
＜0.05% |
| Slew rate |
＞20V/us |
＞20V/us |
＞20V/us |
＞20V/us |
| Damping factor |
＞150 |
＞150 |
＞300 |
＞300 |
| Dynamic range |
≥95dB |
≥95dB |
≥95dB |
≥95dB |
| S/N rate |
≥95dB |
≥95dB |
≥95dB |
≥95dB |
| Input Sensitivity |
0.775Vms/1.0Vms/1.4Vms |
| Voltage gain |
36dB |
37dB |
38dB |
39dB |
| Input impedance |
Balance 20K/unbalance 10K |
| Output circuit Class |
CLASS AB |
| Protection |
DC/Short circuit/Over heat/Over load/Softstart |
| Power voltage/frequency |
AC 220V±10%/50Hz |
| Gross Weight |
23Kg |
25Kg |
30Kg |
31 |
